Specifications
Capacity
| Height of Centers | 8-7/8″ |
| Distance Between Centers | 45″ |
| Swing Over Bed | 17- 11/16″ |
| Swing Over Saddle Sings | 16- 1/8″ |
| Swing Over Cross- Slide | 10-15/32″ |
| Cross- Slide Travel | 9″ |
| Tool Section Maximum | 1″ |
| Coolant | 4 Gallons |
Bed
| Width | 12″ |
| Height | 11-1/2″ |
Headstock
| Spindle Nose (camlock) | D1-6 |
| Spindle Through Hole | 2″ |
| Taper in Reduction Sleeve | Mt#4 |
| Spindle Diameter/ Front Bearing | 3.15 |
| Number of Spindle Speeds | 12 |
| Spindle Speed Range: | 40-2200 Rpm |
Tailstock
| Quill Travel | 6-1/4″ |
| Quill Diameter | 2-5/16″ |
| Quill Taper Hole | Mt#4 |
